Точка доступа Cisco WAP361-E-K9
- Состояние: Новое
- Наличие: Товар в наличии
- P/N: WAP361-E-K9
Описание Точка доступа Cisco WAP361-E-K9
Для каждого региона (Reg Domain) Cisco выпускает свою модель, которая соответствует текущему законодательству этого региона. Ниже представлены основные регионы и их обозначения:
| A | C | E | I | J | K | N | P | S | T |
| FCC (США) | China | ETSI | Israel | TELEC (Japan) | Korea | North America (исключая FCC) | Japan2 | Singapore | Taiwan |
Технические характеристики точки доступа Cisco Small Business AP 361 (WAP361-E-K9):
| Specifications | Description | |
| Standards | IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.3af/at, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) | |
| Cabling type | Category 5e or better | |
| Antennas | Internal antennas optimized for installation on a wall or ceiling | |
| Operating system | Linux | |
| Physical Interfaces | ||
| Ports | 5 - 10/100/1000 Ethernet, with support for 802.3af/at PoE, power port for AC adapter (not included) | |
| Power supply | 802.3af/at PoE and external 48V/1.25A DC power adapter (not included) | |
| Buttons | Reset button | |
| Lock slot | Slot for Kensington lock | |
| LEDs | One multi-function LED | |
| Physical Specifications | ||
| Physical dimensions (W x D x H) | 6.5 x 4.33 x 1.8 in. (165 x 110 x 45.75 mm) | |
| Weight | 1.06 lbs or 480 g | |
| Network Capabilities | ||
| VLAN support | Yes | |
| Number of VLANs | 1 management VLAN plus 16 VLANs for SSIDs | |
| 802.1X supplicant | Yes | |
| SSID-to-VLAN mapping | Yes | |
| Auto-channel selection | Yes | |
| Spanning Tree | Yes | |
| Load balancing | Yes | |
| IPv6 | Yes ● IPv6 host support ● IPv6 RADIUS, syslog, Network Time Protocol (NTP) | |
| Layer 2 | 802.1Q-based VLANS, 16 active VLANS plus 1 management VLAN | |
| Security | ||
| WPA, WPA2 | Yes, including Enterprise authentication | |
| Access control | Yes, management access control list (ACL) plus MAC ACL | |
| Secure management | HTTPS | |
| SSID broadcast | Yes | |
| Rogue access point detection | Yes | |
| Mounting and Physical Security | ||
| Multiple mounting options | Mounting bracket included for easy mounting to junction box | |
| Physical security lock | Kensington lock slot | |
| Quality of Service | ||
| QoS | Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), client QoS | |
| Performance | ||
| Wireless throughput | Up to 1.2-Gbps data rate (real-world throughput will vary) | |
| Recommended user support | Up to 128 connective users, 32 active users per radio | |
| Multiple-Access Point Management | ||
| Single Point Setup | Yes | |
| Number of access points per cluster | 8 | |
| Active clients per cluster | 240 | |
| Configuration | ||
| Web user interface | Built-in web user interface for easy, browser-based configuration (HTTP, HTTPS) | |
| Management | ||
| Management protocols | Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour | |
| Remote management | Yes | |
| Event logging | Local, remote syslog, email alerts | |
| Network diagnostics | Logging and packet capture | |
| Web firmware upgrade | Firmware upgradable through web browser, imported or exported configuration file | |
| Dynamic Host Configuration Protocol (DHCP) | DHCP client | |
| IPv6 host | Yes | |
| HTTP redirect | Yes | |
| Wireless | ||
| Frequency | Dual concurrent radios (2.4 and 5 GHz) | |
| Radio and modulation type | Dual radio, orthogonal frequency division multiplexing (OFDM) IEEE 802.11a/n: OFDM (BPSK, QPSK, 16 QAM, 64 QAM) IEEE 802.11ac: OFDM (BPSK, QPSK, 16 QAM, 64 QAM, 256 QAM) | |
| WLAN | 802.11n/ac 2x2 MIMO with 2 spatial streams at 5 GHz 2x2 MIMO with 2 spatial streams at 2.4 GHz 20-, 40-, and 80-Mhz channels for 802.11ac 20- and 40-Mhz for 802.11n PHY data rate up to 1.2 Gbps 802.11 Dynamic Frequency Selection (DFS) | |
| Data rates supported | 802.11a/b/g: ● 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps 802.11n: 6.5 to 300 Mbps ● 20-MHz bandwidth: MCS 0-15 for supported data rates ● 40-MHz bandwidth: MCS 0-15 for supported data rates 802.11ac: 6.5 to 867 Mbps ● 20-MHz bandwidth: MCS 0-9 for supported data rates ● 40-MHz bandwidth: MCS 0-9 for supported data rates ● 80-MHz bandwidth: MCS 0-9 for supported data rates | |
| Frequency band and operating channels | A Regulatory Domain: ● 2.412 to 2.462 GHz; 11 channels ● 5.180 to 5.240 GHz; 4 channels ● 5.260 to 5.320 GHz; 4 channels ● 5.500 to 5.700 GHz; 8 channels ● 5.745 to 5.825 GHz; 5 channels E Regulatory Domain: ● 2.412 to 2.472 GHz; 13 channels ● 5.180 to 5.240 GHz; 4 channels ● 5.260 to 5.320 GHz; 4 channels ● 5.500 to 5.700 GHz; 8 channels | C Regulatory Domain: ● 2.412 to 2.462 GHz; 11 channels ● 5.180 to 5.240 GHz; 4 channels ● 5.260 to 5.320 GHz; 4 channels ● 5.745 to 5.825 GHz; 5 channels K Regulatory Domain: ● 2.412 to 2.472 GHz; 13 channels ● 5.180 to 5.240 GHz; 4 channels ● 5.260 to 5.320 GHz; 4 channels ● 5.500 to 5.620 GHz; 7 channels ● 5.745 to 5.805 GHz; 4 channels |
| Non-overlapping channels | 2.4 GHz ● 802.11b/g ◦ 20 MHz: 3 ● 802.11n ◦ 20 MHz: 3 | 5 GHz ● 802.11a ◦ 20 MHz: 21 ● 802.11n ◦ 20 MHz: 21 ◦ 40 MHz: 9 ● 802.11ac ◦ 20 MHz: 21 ◦ 40 MHz: 9 ◦ 80 MHz: 4 |
| Wireless isolation | Wireless isolation between clients | |
| External antennas | None | |
| Internal antennas | Internal fixed PiFA antenna | |
| Antenna gain in dBi | Maximum antenna gain of 4.35 dBi on 2.4 GHz Maximum antenna gain of 3.96 dBi on 5 GHz | |
| Wireless distribution system (WDS) | Yes | |
| Fast roaming | Yes | |
| Multiple SSIDs | 16 | |
| Wireless VLAN map | Yes | |
| WLAN security | Yes | |
| Wi-Fi Multimedia (WMM) | Yes, with unscheduled automatic power saving | |
| Operating Modes | ||
| Access point | Access point mode, WDS Bridging, Workgroup Bridge mode | |
| Environmental | ||
| Power options | IEEE 802.3af/at Ethernet switch Cisco power injector: SB-PWR-INJ2-xx Cisco AC Adapter – SB-PWR-48V-xx (not included) PoE peak power: 19.2 W (with PSE load) | |
| Compliance | Safety: ● UL 60950-1 ● CAN/CSA-C22.2 No. 60950-1 ● IEC 60950-1 ● EN 60950-1 Radio approvals: ● FCC Part 15.247, 15.407 ● RSS-210 (Canada) ● EN 300.328, EN 301.893 (Europe) ● AS/NZS 4268.2003 (Australia and New Zealand) EMI and susceptibility (Class B): ● FCC Part 15.107 and 15.109 ● ICES-003 (Canada) ● EN 301.489-1 and -17 (Europe) | |
| Operating temperature | 0° to 40°C (32° to 104°F) | |
| Storage temperature | -20° to 70°C (-4° to 158°F) | |
| Operating humidity | 10% to 85% noncondensing | |
| Storage humidity | 5% to 90% noncondensing | |
| System memory | 256 MB RAM 128 MB flash | |
| Package Contents | ||
| ● WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point ● Ceiling and wall mounting kit ● Quick-start guide ● Ethernet network cable | ||
| Minimum Requirements | ||
| ● Switch or router with PoE support, PoE injector, or AC power adapter ● Web-based configuration: Java-enabled web browser | ||
